32
Speed: Measure the rotation speed. The higher the speed value is, the faster the speed
becomes.
Zoom, focus and iris: Click or to adjust zoom, focus and iris.
4.3.3.2 PTZ Function
Select the PTZ function from the drop-down list to call the corresponding functions, including
Scan, Preset, Tour, Pattern, Pan, Go to, Assistant and Light Wiper. See Figure 4-22. For details,
see Table 4-6. Before calling PTZ function, see "4.3.2 Configuring PTZ Function" to configure
PZT function.
If an external PTZ is connected to the camera, the configurations are valid only when the
corresponding functions are available on the external PTZ.
The range of PTZ function (such as preset and tour) depends on the PTZ protocol.
Figure 4-22 PTZ function
Table 4-6 Description of PTZ function
Set the scan number and click Start, the camera moves horizontally at a
certain speed between the set left and right limit. Click Stop to stop
scanning.
Set the preset number and click Go to, the camera quickly positions the
corresponding preset.
Set the tour number and click Start, the camera moves in the order of the
selected presets. Click Stop to stop touring.
Set the pattern number and click Start, the camera moves continuously
according to the operation recording. Click Stop to stop patterning.
Operation recording includes the information of manual operation, focus and
zoom.
Click Start, and the camera rotates 360°at a certain speed in horizontal
direction.
Set the horizontal angle, vertical angle, and zoom. Click Go to to position a
certain point accurately.
Set the assistant number and click Aux On to enable the corresponding
assistant function, and then you can adjust the camera. Click Aux On to
disable the corresponding assistant function.
