58
4.5.2.3.3 Configuring Time Title
You can enable this function when you need to display time in the video image.
Step 1 Select Setting > Camera > Video > Overlay > Time Title.
The Time Title interface is displayed. See Figure 4-52.
Figure 4-52 Time title
Step 2 Select the Enable check box.
Step 3 Select the Week Display check box.
Step 4 Move the time box to the position you want in the image.
Step 5 Click Save.
4.5.2.3.4 Configure Text Overlay
You can enable this function if you need to display text in the video image.
Text overlay and picture overlay cannot work at the same time, and the IPC that connects to
mobile NVR with private protocol would display GPS information as priority.
Step 1 Select Setting > Camera > Video > Overlay > Text Overlay.
The Text Overlay interface is displayed. See Figure 4-53.
