SERVICING
101
PULSE Installaon, Commissioning and Servicing Manual - Revision 19
15.21 Operating System Menu - OS
The OS Menu has five options: OS VER, NETWORK, CLOUDID,
LANCHECK, INTERNET and SYSLOGS
Press F to enter the OS Menu. Press
2
or
8
to scroll through
the five options. Press
to return to the main menu.
The OS Menu has the following six options:
15.21.1 Operating System Version - OS VER
The display will show the operating system version.
15.21.2 Network Options - NETWORK
Allows the network settings to be changed to Off, Ethernet or Wifi to
match the dispenser’s connection to the Data Centre.
Use the cursor keys 4 or 6 to select the required setting.
Press F to confirm changes or
to cancel.
Use the keys
2
or
8
to navigate through other functions of the OS
Menu or press
to return to the main menu.
15.21.3 Data Centre Cloud ID - CLOUDID
The dollars display shows CLOUDID and the litres display shows the
8 digit Cloud ID for the dispenser (O if an ID has not been entered).
Press F to edit the Cloud ID, an asterix will appear next to CLOUDID
to indicate that the function is in edit mode. Use the number keys to
enter the correct ID and press F to save or
to cancel.
Use the keys
2
or
8
to navigate to other menu items.
15.21.4 Check LAN Status - LANCHECK
Displays OK or FAIL after checking connection status between itself
and the router it is using.
15.21.5 Check Internet Status - INTERNET
Displays OK or FAIL after checking that there is an internet connection.
C
L
MENU
OS
$
C
L
LI 1.20
OS VER
$
C
L
ETHERNT
NETWORK
$
C
L
OFF
NETWORK
$
C
L
00245011
CLOUDID
$
C
L
OK
LANCHECK
$
C
L
OK
INTERNET
$
Version 1.20
