7 GENERAL SHIPPING & TRANSPORTATION INFORMATION
Each Gallagher PULSE dispenser is supplied in
protective packaging consisting of a forklift
compatible wood and cardboard crate.
Upon receipt the crate should immediately
be inspected for external damage. If any is
found it should be recorded at once on the
delivery documentation and MUST be notified
to Gallagher in writing (email or fax) within 3
working days;
It is strongly recommended that photographs of
damaged packaging and equipment be sent to
Gallagher to assist the claim process;
All damaged products AND packaging must be
retained for inspection by Gallagher.
Prompt action will significantly assist problem
resolution.
7.1 Handling
Storage conditions must be met during handling and transportation.
Dispensers in their factory supplied packaging are compatible with forklifts. Always insert
forks at the points indicated to avoid tipping to one side.
The estimated maximum external dimensions (cm) and weights (kg) of PULSE dispensers
in their factory-supplied packaging are shown in the following tables.
The prefix V signifies models fitted with Vapour Recovery.
The suffixes (S) and (F) stand for Spreader and Flexi respectively.
Fork Lift Points
TYPE
Weight Width Depth Height
LX 8-Hose Pump 476 201 58 221
LX 6-Hose Pump 398 186 58 221
LX 4-Hose Pump 325 168 58 221
LX 8-Hose Dspnsr 340 200 58 221
LX 6-Hose Dspnsr 287 186 58 221
LX 4-Hose Dspnsr 250 168 58 221
LS 8-Hose Pump 450 167 58 221
LS 6-Hose Pump 370 150 58 221
LS 4-Hose Pump 290 130 58 221
LS 2-Hose Pump 280 120 58 221
LS 8-Hose Dspnsr 300 167 58 221
LS 6-Hose Dspnsr 360 150 58 221
TYPE
Weight Width Depth Height
LS 4-Hose Dspnsr 231 135 58 221
LS 2-Hose Dspnsr 300 120 58 221
V LX 8-Hose Pump 340 200 58 221
V LX 6-Hose Pump 431 186 58 221
V LX 6-Hose Dspnsr 300 176 58 221
V LX 8-Hose Dspnsr 380 200 58 221
CX 8-Hose Pump(S) 400 125 58 175
CX 6-Hose Pump(S) 375 125 58 175
CX 4-Hose Pump(S) 350 125 58 175
CX 8-Hose Dspnsr(S) 233 125 58 176
CX 6-Hose Dspnsr(S) 350 125 58 175
CX 4-Hose Dspnsr(S) 325 125 58 175
Sample
Packaging
