Gallagher PULSE Series - LPG Stack Components; Figure 19� LPG Stack Components

Return Line
Feed Line in
Filter Housing
Front Hose Meter
Rear Hose Hydraulic
Accumulator
Rear Hose Meter
Rear Hose
2 Stage Valve
Front Hose
2 Stage Valve
Pressure Test Point
4-Way Meter
Feed Valve
Return Valve
Front Hose Hydraulic
Accumulator
Excess Flow Valves
Hose Bleed Valves
Thermal Well
Check Valve
INSTALLATION
45
PULSE Installaon, Commissioning and Servicing Manual - Revision 19
7.1 LPG Stack Components
The image of the LPG Stack shown below is as viewed from the front where the filter
housing is located.
Figure 19. LPG Stack Components
