Gallagher PULSE Series - SD Card Setting - SDCARD; Stack Menu - STK MENU

SERVICING
86
PULSE Installaon, Commissioning and Servicing Manual - Revision 19
15.1 SD Card Setting - SDCARD
The SD Card can be set to ACTIVE or LOCKED by pressing the
5
key.

Only remove an SD Card when in the LOCKED mode.
15.2 Stack Menu - STK MENU
The stack menu allows the completion of a hydraulic stack test. This should be
performed for each dispenser to ensure that the fuel supply is flowing freely. It also
flushes the delivery pipes and hoses as well as prime the system. A test can is required.
Stack test is also used to set fast and slow flow rates for each hose. These settings are
used as limits in flow control where flow control is enabled.

Note: Stack menu is only available when comms are physically disconnected.
STK MENU
STK1
L
M010
V**0010
L
CONTROL
OUTPUTS
L
OffOn
Edit mode
Shut
1 3
7 9
2
4 5 6
8
On/Off
SD CARD
L
ACTIVE
SD CARD
L
LOCKED
Open
15.2.1 Stack Test Procedure
Allows user to test hydraulics and adjust slow, fast and flow control
settings.
Enter Service Mode (see Section 13.2 Entering Service Mode)
Use the
2
&
8
keys to scroll through the list until STK MENU is
displayed in the Dollars display. STK1 is shown in the Litres display
Press
4
or
6
to select a different stack (if present) eg: STK2.
Press
F
to enter the stack menu for the selected stack. The control
outputs window displays.
Press
F
to enter the control outputs function.
The Dollars display now shows an “M” for Motor and a row of digits,
indicating the configured motors and their state. (0 = Off 1 = On / Open)
The litres display now shows a “V” for Valve and a row of up to 10 digits
indicating the state of the valves. (0 = Off 1 = On / Open
*
= Edit mode)
A flashing digit indicates the currently selected motor/valve.
Motors and valves can be toggled between On/Off or Open/Shut using
the following keys:
Press
5
to turn On/Off the motor/valve,
4
to navigate left
6
to navigate right,
2
&
8
to navigate up and down.
Dispense fuel, taking note of the actual flow rate once it has
stabilized (after 3-5 seconds of flow)
While delivering fuel the Cents per Litre display will show:
A The percentage that the front valve is open.
B The percentage that the rear valve is open.
C The flow rate of the front valve in L/min.
D The flow rate of the rear valve in L/min.
A B
40 40
38
0
Valve %
Flow rate
C D
$
$
$
$
$
Important Note: Flow rate is only accurate for a single hose per side.

While all motors can be turned on at once this is not recommended for a sustained
period of time.
Version 1.20
