8.1 Pre-Installation Check of Rotor Movement
A harsh knock in transit can affect clearance between the rotor, stator and rotor cover.
Before the belt is installed, test clearance by turning the pulley wheel by hand.
The wheel should move freely. If it is locked up, or excessive resistance is detected, carry
out the realignment procedure below.
8.2 Realignment Procedure
Use a 13mm spanner to loosen the four M8 rotor cover bolts, spin the rotor by hand
until it spins freely, then re-tighten the bolts. There is no particular sequence to tighten.
Tighten to 19-23 Nm.
8.3 Belt Tension
Tighten drive belt to 35lb.
8.4 Vacuum and Pressure Testing
IMPORTANT:
Vacuum / pressure gauges should be of the thread type G ¼ B and must be suitably rated
to record the vacuum or pressure of the pump. Vacuum is tested at the plug located at
the centre of the filter cover. Pressure is tested at the centre of the control valve cover.
To psi mbar bar atm Pa kPa MPa mmH
2
O in.H
2
O mmHg
in.Hg kg/cm
2
From
psi
1
68.95 0.0689 0.0681 6895 6.895 0.006895 703.8 27.71 51.715 2.036 0.0704
mbar
0.0145 1 0.001 0.999967 100 0.100 0.0001 10.21 0.402 0.75 0.0295 0.00102
bar
14.504 1000 1 0.987 100000 100 0.1 10210 401.9 750.1 29.53 1.02
atm
14.7 1013.25 1.01325 1 101325 101.325 0.1013 10343 407.2 760.0 29.92 1.033
Pa
0.000145 0.01 0.00001 0.00001 1 0.001 0.000001 0.102 0.00402 0.0075 0.000295 0.00001
kPa
0.14504 10.0 0.01 0.00987 1000 1 0.001 102.07 4.019 7.5 0.295 0.0102
MPa
145.04 10000 10 9.87 1000000 1000 1 101971.6 4014.6 7500.6 295.3 10.2
mmH2O
0.001421 0.098 0.000098 0.000097 9.8 0.0098 0.0000098 1 0.0394 0.0735 0.00289 0.0001
in.H2O
0.0361 2.488 0.002488 0.00246 248.8 0.2488 0.00025 25.4. 1 1.866 0.0735 0.00254
mmHg
0.01934 1.333 0.001333 0.001316 133.3 0.1333 0.00013 13.61 0.536 1 0.0394 0.00136
in.Hg
0.4912 33.86 0.03386 0.03342 3386 3.386 0.00386 345.7 13.61 25.4 1 0.0345
kg/cm²
14.22 980.7 0.9807 0.968 98067 98.067 0.0981 10010 394.1 735.6 28.96 1
PRESSURE CONVERSION TABLE
For more detail, see the Bennett Pump Manual at: https://www.bennettpump.com/files/
oem-components/oem-components-manuals/56-bennett-t140-high-flow-pumping-unit-
operation-service-and-parts-manual/file
