SERVICING
92
PULSE Installaon, Commissioning and Servicing Manual - Revision 19
15.8 LPG Menu
The LPG Menu has five options - MTR SECU, TEST, XS FLOW, MTR CAL, and MTR SIDE. Each
option allows the following functions.
L
LPG MENU
1. MTR SECU - Check the security setting of each LPG meter.
2. TEST - Enables testing pump accuracy against the test meter.
3. XS FLOW - Set high flow limit for excess flow monitoring and control.
4. MTR CAL - Enter the Trade Verification test values for meter
calibration.
5. MTR SIDE - Check and or edit the bus address of the LPG meters to
assign fuel points.
Press
F
to enter the LPG menu.
Navigate through the options using
2
or
8
.
15.8.1 Check Meter Security Switch State - MTR SECU
The Meter Security Switch menu option is a read only screen and displays the security
switch state of each LPG meter. It does NOT allow you to change the ON/OFF state. This
is done manually using the physical security switch located on the LPG meter.
FP2
L
MTR SECU
C
L
MTR SECU
ON
L
TEST
OFF
Note that the meter security needs to be in the OFF position before
the meter is calibrated.
Use
4
and
6
to toggle between fuel points.
Press
F
to view the security switch status for the selected Fuel Point.
Note: There is a delay of up to 10 seconds to read this security switch
status, (MTR Secu*) indicates waiting reply.
Press
to exit back to the fuel point.
Hold
to exit service mode and begin LPG calibration test using TEST mode.
Press
F
to cancel TEST mode, or will time out after 15 minutes of no activity.
Non-LPG hoses disabled in test mode.
15.8.2 Enables LPG test mode - TEST
Used for Trade Verification.
Enables testing the accuracy of the pump against the test meter.
Use
4
and
6
to switch between fuel points for calibration check.
Press 5 to toggle test mode on/off for the selected fuel point.
$
$
$
$
Version 1.20
