IIDTool
GAP Diagnostic 2023-09-12 All Rights Reserved
User Manual G3 units: Version 37, Firmware V4.0
4.8 Function “ Live Values ” (LV)
4.8.1 Denition
This function allows viewing of current values or status of a sensor or actuator. For a list of available
and tested values for your vehicle, please consult the list of features on the IIDTool webpage.
Access
1- Perform the initial stages of access (section 4.1.3)
2- Select “Live Values” function
3- Select ‘‘Conrmed’’ or ‘‘Complete’’ list
4- Select an ECU or use the search box
5- Consult section 4.8.2 for live value selecting and viewing.
WARNING
The driver should never observe a live value while driving. For
safety reasons, only the passenger should read a live value
while the vehicle is on the move.
Before viewing live values, please read the following notes.
Notes:
• It is normal to see warning light(s) turning on when viewing live values.
• When broadcasting live values, some ECUs will stop sending messages on the networks. As a
result, other ECUs will interpret this as a communication error. While not mandatory, we strongly
suggest performing a clear fault of all ECUs after viewing live values. If you have faults currently
