Once calibration is done, the vehicle baseline height can be adjusted to the user requirements. Navi-
gate to the Height function and adjust accordingly (see section 4.4.4).
Original standard heights
These are the original baseline heights for your vehicle. Tire size has no eect when measuring from
the center of the wheel.
Table 24. Original standard height
Original Standard height values Wheel
Centre to lower edge of wheel arch
Front (mm) Rear (mm)
Range Rover L322 493 483
Discovery 3-4/LR3-4 L319 466 485
Range Rover Sport L320 461 465
Range Rover L405 and L494 up to 2017 471 468
Range Rover L405 SVA-Dynamic 2018+ 464 461
L405 all including SV Autobiography 2018+ 472 469
Range Rover L460 487 483
Range Rover Sport L494 2018-2022 464 461
Range Rover Sport L461 2023+ 487 483
Range Rover Velar L560 457 468
Discovery L462 466 462
Defender L663 509 520
