4.9.2 EPB Electronic Parking Brake ECU
Select Normal or Service position (L322-06, L319-04, L320-05)
This routine will allow servicing the rear brakes. For L405, L494, L538 and L359 2013+, the function is
located in the service test menu, section 4.7.3
Usage
Select Service position when servicing the brakes and Normal when nished.
Preparation
• Disengage the parking break
• The ignition must be turned ON without the engine running.
Note: On vehicles using the old nomenclature, Latching position is the equivalent of Normal position
while Mounting is the Service position.
