86
IIDTool
GAP Diagnostic 2023-09-12 All Rights Reserved
User Manual G3 units: Version 37, Firmware V4.0
Possible adjustments for this example :
Sensor Raising Lowering
Front Left 200 - 157 = 43 No limit
Front Right 200 - 138 = 62 No limit
Rear Left 200 - 180 = 20 No limit
Rear Right 200 - 66 = 34 No limit
Table 23. Possible adjustments for this example
Using Adjust Front sub-function
The front axle can be raised by a maximum of 200 - 157 = 43 mm. The front axle can be lowered wit-
hout a maximum limit in this case.
Using Adjust Rear sub-function
The rear axle can be raised by a maximum of 200 - 180 = 20 mm. The rear axle can be lowered without
a maximum limit.
Using Adjust All sub-function
The smallest of the limitations applies. The height of the two axles can be increased simultaneously to
a maximum of 200-180 = 20 mm. Both axles can be lowered without maximum limits.
The IIDTool automatically calculates these values and allows only changes within these parameters.
