User bus addresses
The ZP3 auxiliary boards may assume any address in the User Bus (group 10) address range.
Each auxiliary board represents a range of point addresses; 8-way, 16-way, or 24-way. The
address range is defined by the board address, which is set with a Dipswitch on each board. The
board address defines the first 8-point addresses on the board. For boards with more than 8-
ways, each subsequent group of 8-ways automatically assumes the next board address after the
Dipswitch setting. Therefore, a 24-way board would use 3 board addresses, the first being set on
the Dipswitch, the other two-board addresses following-on by assumption.
Note: Accessory board Dipswitch 8 must be set OFF to link to the User Bus.
Auxiliary
Board
Address
Dipswitch
User Bus
Point
Address
Auxiliary
Board
Address
Dipswitch
User Bus
Point
Address
Auxiliary
Board
Address
Dipswitch
User Bus
Point
Address
Auxiliary
Board
Address
Dipswitch
User
Bus
Point
Address
32 000 - 007 56 192 – 199 80 384 – 391 104 576 – 583
33 008 – 015 57 200 – 207 81 392 – 399 105 584 – 591
34 016 – 023 58 208 – 215 82 400 – 407 106 592 – 599
35 024 – 031 59 216 – 223 83 408 – 415 107 600 – 607
36 032 – 039 60 224 – 231 84 416 – 423 108 608 – 615
37 040 – 047 61 232 – 239 85 424 - 31 109 616 – 623
38 048 -055 62 240 – 247 86 432 - 439 110 624 – 631
39 056 – 063 63 248 – 255 87 440 – 447 111 632 – 639
40 064 – 071 64 256 – 263 88 448 – 455 112 640 - 647
41 072 – 079 65 264 – 271 89 456 – 463 113 648 – 655
42 080 - 087 66 272 – 279 90 464 – 471 114 656 – 663
43 088 – 095 67 280 – 287 91 472 – 479 115 664 – 671
44 096 – 103 68 288 – 295 92 480 – 477 116 672 – 679
45 104 – 111 69 296 - 303 93 478 – 495 117 680 – 687
46 112 – 119 70 304 – 311 94 496 – 503 118 688 – 695
47 120 – 127 71 312 – 319 95 504 – 511 119 696 – 703
48 128 – 135 72 320 – 327 96 512 – 519 120 704 – 711
49 136 – 143 73 328 – 335 97 520 – 527 121 712 – 719
50 144 - 151 74 336 – 343 98 528 – 535 122 720 – 727
51 152 – 159 75 344 – 351 99 536 – 543 123 728 – 735
52 160 – 167 76 352 – 359 100 544 – 551 124 736 – 743
53 168 – 175 77 360 – 367 101 552 – 559 125 744 – 751
54 176 – 183 78 368 – 375 102 560 – 567 126 752 – 759
55 184 – 191 79 376 - 383 103 568 - 575 127 760 - 767
