GE Security ZP3 - Menu Structure; Figure 55: Menu Structure (Sheet 1 of 3)

ZP3 Fire Control Panel Installation, Commissioning and Maintenance Manual
REV 11 (ISS 08/03/2010) Page 65
Menu structure
Figure 55, Figure 56 and Figure 57 show the menu structure of the Setup menu option.
Figure 55: Menu structure (sheet 1 of 3)
S
ETUP MENU
Zoning
I/O Mapping
Points
Viewing
Edit
Clear
Edit
Allocation and Messages
Fire coincidence detection
Zone allocation
Zone messages
Fire coincidence detection
Single zone
All zones
Single zone message
All zone messages
Sensitivity - point
Sensitivity - point range
AVF - point
AVF - point range
Zones
Messages
Sounder
Detector test
Point type
AGV allocation
Sensitivity - point
AVF (fire) - point
Zones
Edit
Display
Clear single
Clear all
Sounder
Detector test
Point type
I/O Map view
I/O map edit
I/O map clear
Global reactivation
Individual
settings
View
Sensitivity
and AVF
Sensitivity
and AVF
Messages
Continued
on next page
AGV allocation
3024-02
