ZP3 Fire Control Panel Installation, Commissioning and Maintenance Manual
Page 84 REV 11 (ISS 08/03/2010)
System address list
System bus addresses
The following are System Bus (group-09) addresses. They are pre-programmed, and cannot be
changed from the specified functions. Outputs can be linked to these addresses to automatically
mimic their functions.
Note: Accessory board Dipswitch 8 must be set ON to link to the System Bus.
Auxiliary
Board
Dipswitch
Setting
System
Bus
Address
Function Auxiliary
Board
Dipswitch
Setting
System
Bus
Address
Function
000 Zone 0 Fire LED 024 Zone 24 Fire LED
001 Zone 1 Fire LED 025 Zone 25 Fire LED
002 Zone 2 Fire LED 026 Zone 26 Fire LED
003 Zone 3 Fire LED 027 Zone 27 Fire LED
004 Zone 4 Fire LED 028 Zone 28 Fire LED
005 Zone 5 Fire LED 029 Zone 29 Fire LED
006 Zone 6 Fire LED 030 Zone 30 Fire LED
000
007 Zone 7 Fire LED
003
031 Zone 31 Fire LED
008 Zone 8 Fire LED 032 Zone 32 Fire LED
009 Zone 9 Fire LED 033 Zone 33 Fire LED
010 Zone 10 Fire LED 034 Zone 34 Fire LED
011 Zone 11 Fire LED 035 Zone 35 Fire LED
012 Zone 12 Fire LED 036 Zone 36 Fire LED
013 Zone 13 Fire LED 037 Zone 37 Fire LED
014 Zone 14 Fire LED 038 Zone 38 Fire LED
001
015 Zone 15 Fire LED
004
039 Zone 39 Fire LED
016 Zone 16 Fire LED 040 Zone 40 Fire LED
017 Zone 17 Fire LED 041 Zone 41 Fire LED
018 Zone 18 Fire LED 042 Zone 42 Fire LED
019 Zone 19 Fire LED 043 Zone 43 Fire LED
020 Zone 20 Fire LED 044 Zone 44 Fire LED
021 Zone 21 Fire LED 045 Zone 45 Fire LED
022 Zone 22 Fire LED 046 Zone 46 Fire LED
002
023 Zone 23 Fire LED
005
047 Zone 47 Fire LED
