GE Security ZP3 - Page 97

ZP3 Fire Control Panel Installation, Commissioning and Maintenance Manual
REV 11 (ISS 08/03/2010) Page 85
Auxiliary
Board
Dipswitch
Setting
System
Bus
Address
Function Auxiliary
Board
Dipswitch
Setting
System
Bus
Address
Function
048 Zone 48 Fire LED 080 Zone 80 Fire LED
049 Zone 49 Fire LED 081 Zone 81 Fire LED
050 Zone 50 Fire LED 082 Zone 82 Fire LED
051 Zone 51 Fire LED 083 Zone 83 Fire LED
052 Zone 52 Fire LED 084 Zone 84 Fire LED
053 Zone 53 Fire LED 085 Zone 85 Fire LED
054 Zone 54 Fire LED 086 Zone 86 Fire LED
006
055 Zone 55 Fire LED
010
087 Zone 87 Fire LED
056 Zone 56 Fire LED 088 Zone 88 Fire LED
057 Zone 57 Fire LED 089 Zone 89 Fire LED
058 Zone 58 Fire LED 090 Zone 90 Fire LED
059 Zone 59 Fire LED 091 Zone 91 Fire LED
060 Zone 60 Fire LED 092 Zone 92 Fire LED
061 Zone 61 Fire LED 093 Zone 93 Fire LED
062 Zone 62 Fire LED 094 Zone 94 Fire LED
007
063 Zone 63 Fire LED
011
095 Zone 95 Fire LED
064 Zone 64 Fire LED 096 Zone 96 Fire LED
065 Zone 65 Fire LED 097 Zone 97 Fire LED
066 Zone 66 Fire LED 098 Zone 98 Fire LED
067 Zone 67 Fire LED 099 Zone 99 Fire LED
068 Zone 68 Fire LED 100 Zone 100 Fire LED
069 Zone 69 Fire LED 101 Zone 101 Fire LED
070 Zone 70 Fire LED 102 Zone 102 Fire LED
008
071 Zone 71 Fire LED
012
103 Zone 103 Fire LED
072 Zone 72 Fire LED 104 Zone 104 Fire LED
073 Zone 73 Fire LED 105 Zone 105 Fire LED
074 Zone 74 Fire LED 106 Zone 106 Fire LED
075 Zone 75 Fire LED 107 Zone 107 Fire LED
076 Zone 76 Fire LED 108 Zone 108 Fire LED
077 Zone 77 Fire LED 109 Zone 109 Fire LED
078 Zone 78 Fire LED 110 Zone 110 Fire LED
009
079 Zone 79 Fire LED
013
111 Zone 111 Fire LED
