ZP3 Fire Control Panel Installation, Commissioning and Maintenance Manual
Page 118 REV 11 (ISS 08/03/2010)
Enable all
Menu path Maintenance/Enable all
Purpose This menu provides a quick method to enable points and outputs or both. The menu options
available are: Enable all…….
Points This option is used to enable all system Z-loop devices. This includes sensors, callpoints,
devices, zones and loop or base sounders.
Outputs This option is used to enable all panel outputs. This includes all Extinguishing Control Units,
panel sounder outputs and the remote manned centre output.
Points and outputs This option is used to enable all Z-loop devices & panel outputs, i.e. selecting both options above.
Reports to display
Menu path Maintenance/Reports to display
Purpose This menu provides a selection of reports to view on the display. Report messages may be
manually or automatically scrolled. The reports that may be viewed are listed below with
a brief description of each report.
Point analogues A real time display is shown per point of analogue values. Point ID, sensitivity, threshold
and condition are also displayed. Use the scroll feature to view the next/previous point
analogues.
Checksums Two numeric values are displayed, a calculated and a stored value. If the values are not
equal, data corruption has occurred.
Zoning This option is used to generate a report showing which points are allocated to a zone. The
zone number and the first point allocated to the zone is displayed. Use the scroll feature
to display the next/previous point allocated to the zone.
I/O mapping This option is used to display a report of all the programmed outputs with their respective
programmed configuration details and associated input triggers. Use the scroll keys to
view the next/previous outputs and left/right arrow keys to view associated inputs.
Service This option is used to generate a report of all sensors that require servicing. A service
condition indicates that the sensor should be cleaned or replaced as soon as possible.
Use the scroll feature to display the next/previous point. The point displayed may be
limited to a date range.
Pre-service This option is used to generate a report of all sensors that are in a pre-service condition. A
sensor in a pre-service condition does not need immediate attention. Pre-service reports
allow forward planning by the installer. Use the scroll feature to display the next/previous
point. The points displayed may be limited to a date range.
Reports to printer
Menu path Maintenance/Reports to printer
Purpose This menu initiates a Keypad test. Once selected, the panel reports any key pressed on
the panel via the LCD. The operator can use this function to check that the keypad is
functional. Press any key twice to exit.
I/O map This option is used to generate a printout of all I/O mapping entries.
Points analogue This option is used to generate a snapshot of all points analogues at the time of the print
report initialisation. Enter an address range of points to print or accept the default value
(all).
Service reports This option is used to generate a report of all sensors that require servicing or are in a
pre-service condition. A service condition indicates that the sensor should be cleaned or
replaced as soon as possible. A sensor in a pre-service condition does not need
immediate attention, but serves as a warning that the sensor will reach a service
condition in the future.
Zoning This option is used to generate a printout of which points are allocated to a zone. The
printout shows the zone number and the points assigned within it.
