ZP3 Fire Control Panel Installation, Commissioning and Maintenance Manual
Page 114 REV 11 (ISS 08/03/2010)
Maintenance menu
Introduction
The panel has built in software functions for providing maintenance diagnostics and support.
These functions are accessed via the maintenance menu, using the panel keypad. Menu
functions are displayed on the LCD screen.
Menu access
Access to the menus is via the panel keypad (see Figure 68). Each key is described in Table 31.
Figure 68: Keypad
Table 31: Keypad description
Key/s Name Description
Numeric keys Used to enter the number sequences
MENU key Gives access to the Menu Screen
ENTER key Used to confirm data entry and save data
ESCAPE key Exits a function and returns to the previous
level
HOME key Exits all menu's and returns to the system
home screen
FUNCTION keys Used within certain menus
NAVIGATION keys Used to move up/down/left and right
