ZP3 Fire Control Panel Installation, Commissioning and Maintenance Manual
Page 126 REV 11 (ISS 08/03/2010)
Extinguishing control unit
The Extinguishing control unit in particular makes extensive use of slots 5 and 6 to indicate status.
These analogues are shown in Table 35 for slot 5 and Table 36 for slot 6.
Table 35: Extinguishing control unit – slot 5 (address 1)
Details Nominal value
Digital counts
Normal idle value 39 -
65
Manual when door locked
68-100
Loss of si
g
nal < 39
General
p
anel fault 103 –
132
Power su
pp
l
y
fault > 163
Rela
y
o
p
erated 141
163
Table 36: Extinguishing control unit – slot 6 (address 1)
Details Nominal value
Digital counts
Fault – low idle < 39
Auto released 39 –
65
Manual released 68 –
100
S
y
stem locked-off (released)
103 –
132
Auto non-released 141 –163
S
y
stem locked-off (non-released) 166 –
195
Manual (non-released) > 198
