ZP3 Fire Control Panel Installation, Commissioning and Maintenance Manual
Page 2 REV 11 (ISS 08/03/2010)
Specification
Refer to Table 4 for a detailed specification of the ZP3 Fire Control Panel.
Table 4: ZP3 Fire control panel specification
Description Specification/
parameters
Remarks
Specification Compliance
Fire alarm panel Complies with European Standard EN54-2
Power supply Complies with European Standard EN54-4
Electro-magnetic CE Marked. Complies with European Directive 89/336/EEC.
Complies with standards BS EN50081, BS EN50082, and IEC 950
IP rating IP30: For indoor use only
Loop
Loop protocol ZP addressable loop protocol
Isolators Up to 16 per loop (advisable to use 11)
Capacity
ZP3 4-loop panel Devices - 508 Loop devices, such as sensors, sounders, interfaces
Zones – 128 128 digital display, 50 built in zone LED's
Outputs - 768 Located on the I/O Bus (local and/or remote)
ZP3 2-loop panel Devices - 254 Loop devices, such as sensors, sounders, interfaces
Zones – 128 128 digital display, 50 built in zone LED's
Outputs - 768 Located on the I/O Bus (local and/or remote)
ZP3 1-loop panel Devices - 127 Loop devices, such as sensors, sounders, interfaces
Zones – 128 128 digital display, 50 built in zone LED's
Outputs - 768 Located on the I/O Bus (local and/or remote)
Power Supply Inputs and Outputs
Input
Mains voltage 230 VAC +10%, -15%
Mains frequency
50 Hz ( 15%)
Mains current (maximum) 1 A
Power 130 W
CIE input voltage 21.0 to 27.6 VDC
Auxiliary Output Voltage
Output voltage (mains on) 24 VDC nominal See note 1
Output voltage (mains off) 19.0 to 27.6 VDC See note 1
Battery charging voltage 27.6 VDC
at 20C temperature compensated
Maximum ripple (at full load) 500 mV peak
