ZP3 Fire Control Panel Installation, Commissioning and Maintenance Manual
REV 11 (ISS 08/03/2010) Page 3
Description Specification/
parameters
Remarks
Output Current
Total continuous 2.6 A at 21 VDC See note 2
Total continuous 3.0 A at 24 VDC See note 2
Total peak 5.5 A at 24 VDC See note 2
Panel operation (quiescent) 0.4 A See note 3
Panel operation (fire) 0.6 A See note 3
Battery charging (JP6 IN - default) 1.4 A
Battery charging (JP6 OUT) 1.0 A
Available to user (continuous non
fire alarm)
1.2 A See note 4
Available to user (continuous in fire
alarm)
2.5 A See note 5
Supply Input Limits
High voltage alarm 28.5 VDC
First battery low-voltage notification:
battery low warning local
22.3 VDC
Second battery low-voltage
notification: low/no battery local
21.0 VDC
Batteries
Type 2 x 12V Sealed lead-acid as per Power supply and battery
calculations on page 50
Make and model — Kung Long WP26-12
GE BS129
Battery SLA type 26 A/H Maximum size that can be fitted into a type-A cabinet
Lithium battery CR2325 6 VDC Time and date retention
Panel Power Requirements
Panel (quiescent at 24 VDC) 450 mA Load of panel only, excluding any external devices
Panel (alarm at 24 VDC) 500 mA Load of panel only, excluding any external devices
Per Loop (quiescent at 24 VDC) 150 mA Fully loaded loop, with 127 ZP devices, not in alarm
Per Loop (alarm at 24 VDC) 300 mA Maximum available per loop, for driving all devices
Panel total (alarm at 24 VDC) Dependent upon external devices when in alarm
