ZP3 Fire Control Panel Installation, Commissioning and Maintenance Manual
Page 86 REV 11 (ISS 08/03/2010)
Auxiliary
Board
Dipswitch
Setting
System
Bus
Address
Function Auxiliary
Board
Dipswitch
Setting
System
Bus
Address
Function
112 Zone 112 Fire LED 144 Points Disabled LED
113 Zone 113 Fire LED 145 Info LED
114 Zone 114 Fire LED 146 Alarms Delayed LED
115 Zone 115 Fire LED 147 Rem/ Alarm Delayed LED
116 Zone 116 Fire LED 148 GC Function Delayed LED
117 Zone 117 Fire LED 149 Day Mode LED
118 Zone 118 Fire LED 150 Test Condition LED
014
119 Zone 119 Fire LED
018
151 Point Alarm LED
120 Zone 120 Fire LED 152 System On LED
121 Zone 121 Fire LED 153 LCD Backlight On
122 Zone 122 Fire LED 154 Reserved - for future use
123 Zone 123 Fire LED 155 Reserved - for future use
124 Zone 124 Fire LED 156 Reserved - for future use
125 Zone 125 Fire LED 157 Reserved - for future use
126 Zone 126 Fire LED 158 Buzzer Output
015
127 Zone 127 Fire LED
019
159 Info #2 LED
128 Zone 128 Fire LED 160 Common Disable #2 LED
129 Common Fire LED 161 Common Fault #2 LED
130 Common Fire LED #2 162 Night Mode LED
131 Sounders Active LED 163 Alarm Silenced LED
132 Remote Alarm Active
LED
164 More Up LED
133 Control O/P Active
LED
165 More Down LED
134 Common Fault LED 166 Zone Pre-alarm
016
135 Alarm(Sounder)
Fault LED
020
167 Zone Fault
136 Remote Alarm Fault
LED
168 More Time
137 Control O/P Fault LED 169 Points Fault
138 System Fault LED 170 Double Knock
139 Common Disable LED 171 Security (door switches?)
140 Alarm Disable LED 172 Common Fire LED’s
141 Rem. Alarm Disabled
LED
173 Fire Alarm Relays 1+2
142 Control O/P Disabled
LED
174 Silence Alarm Key
017
143 Zone Disabled LED
021
175 Sound Alarm Key
