ZP3 Fire Control Panel Installation, Commissioning and Maintenance Manual
REV 11 (ISS 08/03/2010) Page 5
Description Specification/
parameters
Remarks
Control buttons/keys
Help Button Displays operator instructions on-screen
View fire alarm Button Displays “Fire Alarms by Zone” screen
View fault alarm Button Displays “Fault Alarms by Zone” screen
View disabled zones/devices Button Displays “Disabled Devices by Zone” screen
View other Button Displays “Other Events by Category” screen
View points/devices Button Displays alarms by individual device
Accept Button Silence built-in panel buzzer during an alarm
Reset Button Resets system to normal after an alarm
Silence alarms Button Silences all field sounders that are active
Sound alarms Button Activates all (or selected) field sounders
Restore disabled alarms/RMC Button Restores sounders or RMC alarms that are disabled
Scroll events (more) Button Manually scrolls list of alarms on LCD screen
Controls ON/OFF Keyswitch Enables or disables front panel controls
Operator menu/keypad Keypad For operator, maintenance and setup menus
Indicators
Fire (common) LED (dual) Red
Fault (common) LED (dual) Yellow
Disabled (common) LED (dual) Yellow
Other (common) LED (dual) Yellow
Alarms silenced LED Yellow
Sound alarms key pressed LED Yellow
Night mode (optional) LED Green
Day mode (optional) LED Yellow
More alarms LED Yellow
Sounders active LED Red
Remote centre alarm active LED Red
Control output active LED Red
System fault LED Yellow
Zone fault LED Yellow
Sounder fault LED Yellow
Remote centre alarm fault LED Yellow
Control output fault LED Yellow
Zone disabled LED Yellow
Point disabled LED Yellow
Sounders disabled LED Yellow
Remote centre alarm disabled LED Yellow
Control output disabled LED Yellow
