[EN] English - K0460 Instrument communications 5-1
Chapter 5: Instrument
communications
5.1 Introduction
This chapter gives a description of these items:
• the procedures to connect the instrument to a computer with
the optional USB mini Type B cable.
For a full list of optional accessories, refer to Section 1.4.
5.2 Connect to a
computer (USB)
A USB mini Type B connector connected between the
instrument and a computer can be used to download or upload
data to the SD card, see Chapter 6 (Datalog operation).
Note: If the power supply fails, the data will not transmit
correctly.
When the connections are complete, files can be moved
between the computer and the DPI 620-IS calibrator using
normal file manager software (for example, Windows Explorer).
Note: The computer can get access to the internal memory of
the DPI 620-IS calibrator by using Active Sync.
Step Procedure
1. Start the computer.
2. On the right-hand side of the instrument
(Figure 1-3), use the rubber recess to pull down
the cover for the connections.
3. Push the mini Type B end of the USB cable into
the USB socket on the instrument.
4. Set the instrument power on.
