[EN] English - K0460 Datalog operation 6-1
Chapter 6: Datalog operation
6.1 Introduction
This section gives examples of how to log measurements with
time and date over a set time period or on a key press. Logged
data is stored in a user defined file. The instrument logs all the
tasks currently enabled.
Stores this data internally but can be downloaded (transferred)
through the mini Type B USB serial port. The data transfer to
the PC uses Active Sync.
To enter data logging select configuration menu and press data
logging.
6.2 Set-up
To set the data logging process:
After data logging the data file can be used in the data logging
menu as follows:
Selection Action
Filename Enter name using three-page screen alpha/numeric
key-pad.
Trigger Set to Key Press to activate on pressing of bottom
right key or Periodic set to activate on time set in
period.
Period Sets the time period of data recording using numeric
keys and HH:MM:SS format.
Start Starts data logging.
