6-50 CIC Pro™ 2026419-033E
Configuration
NOTE
An alarm will sound when removing admitted beds from the display if the beds
are not viewed on another CIC Pro center.
Complete the following procedure to configure the Display Configuration settings:
1. From the multi-patient viewer, click Setup CIC.
2. Log on to Setup CIC with service access on page 4-5.
3. On the CIC Setup screen, click Display Configuration.
4. On the Display Configuration tab, change the settings as needed:
Option Function
Columns Set the number of columns of patient windows displayed in the multi-patient viewer.
Rows Set the number of rows of patient windows displayed in the multi-patient viewer.
Screen Calibration Display the Screen Calibration window used for adjusting the displayed waveform gain and sweep speed of
non-touchscreen displays. See Screen calibration on page 6-55.
To Next Page
