Installation
2026419-033E CIC Pro™ 5-17
printer. To do this, use the controls and appropriate manufacturer’s instructions
enclosed with the printer.
For configuration information, refer to Configure USB laser printers on page 6-28 or
Configure network laser printers on page 6-14.
Connect the digital writer
NOTE
The PRN 50-M must use software v2B or later to operate properly with the CIC
Pro center and telemetry systems.
1. Screw the PRN 50-M adapter into the RS232 2 port on the CIC Pro center.
2. Connect the supplied Category 5 cable into the adapter and into the PRN 50-M
port.
3. Load the printer with paper.
4. Insert the digital writer power cable into an electrical power outlet.
Change writer paper
Complete the following procedure to replace the 2-inch digital writer paper:
1. Press the button on the top of the writer to open the writer door.
To Next Page
