11-6 CIC Pro™ 2026419-033E
Reload software
NOTE
The reload process will run twice when option 1 is selected from the menu;
once for the flash (solid-state) drive and once for the hard disk drive.
The following messages will be displayed upon a successful restore:
CIC image has been restored
HDD is cleaned and initialized
Remove the USB stick then reboot the system
8. Remove the USB memory stick.
NOTE
If a USB memory stick that contains the CIC Pro center software image
is not removed from the CIC Pro center, step 6 is repeated. If this
occurs, select option 2 to quit.
If a USB memory stick that contains licenses or data other than the CIC
Pro center restore image, then Operating system missing will be
displayed.
9. Power down and power up the CIC Pro center using the power switch.
NOTE
Upon first boot, the screen will be blank for a few minutes, and then the
following warning message will be displayed:
Setup is in progress, do not close this window.
System will reboot automatically in approximately 2 minutes.
10. Verify that the CIC Pro center is defaulted to the following IP addresses:
a. If you have not already logged in to Webmin, Log on to the Webmin service
interface on page 4-7.
b. Click Configuration > Network.
11. Configure the system as necessary as described in Configuration on page 6-1.
NOTE
If the System Resource Indicator turns yellow or red during configuration,
refer to Environment Monitor messages on page 8-19.
Network Field Default value
IX IP address 172.18.1.1
Netmask 255.255.0.0
Default gateway 172.18.254.254
MC IP address 172.16.1.1
Netmask 255.255.0.0
Default gateway <none>
