D20E ETHERNET I/O MODULE INSTRUCTION MANUAL GE INFORMATION 129
D20E Ethernet I/O Module
Appendix C: D20E Module DNP3
Server Profile
D20E Module DNP3 Server Profile
This appendix provides:
• DNP3 IED protocol document on page 129
• DNP3 object implementation table on page 131
DNP3 IED protocol document
The following document is provided for information purposes.
D20E DNP3 Server
Vendor Name: GE Grid Solutions
Device Name: D20E Ethernet I/O Module
Highest DNP Level Supported: Device Function:
For Requests Level 2  Master  Slave
: For Responses :Level 2
• Notable objects, functions, and/or qualifiers supported in addition to the highest DNP levels supported (the
complete list is described in the attached table):
Maximum Data Link Frame Size (octets): Maximum Application Fragment Size (octets):
Transmitted 292 Transmitted 2048
Received 292 (must be 292) Received 2048 (must be > 249)
Maximum Data Link Retries: Maximum Application Layer Retries:
 None  None
 Fixed at ________  Configurable, range, 0 to 255
 Configurable, range 0 to 255
Requires Data Link Layer Confirmation:
 Never
 Always
 Sometimes If 'Sometimes', when? ______________________
 Configurable If 'configurable', how? ______________________
Requires Application Layer Confirmation:
 Never
 Always (not recommended)
