APPENDIX C: D20E MODULE DNP3 SERVER PROFILE
D20E ETHERNET I/O MODULE INSTRUCTION MANUAL GE INFORMATION 131
DNP3 object implementation table
The information listed in Table 46 indicates the following:
• A blank in the Response column indicates that the DNP3 Server does not support the
object number and variable number combination. The DNP3 Server only supports the
combination that is in accordance with the object number, variable number and
qualified codes listed in the table.
•A Y in the Used column indicates that the DNP3 Server either:
– Processes the combination of this object number and variable number, or
– Ignores the combination.
•The bold font indicates the type of request that the DNP3 Server is able to send.
• The regular font (not bold) indicates the type of response message the DNP3 Client is
able to process.
Table 46: Object implementation table
Object Request
(see Table 48)
Response
(see Table 49)
Number Variable Description FC (hex) Qualifier (hex) FC (hex) Used
1 0 Binary Input - All Variations 1 All valid
1 1 Binary Input 1 81,82 Y
1 2 Binary Input with Status 1 81,82 Y
2 0 Binary Input Change - All Variations 1 All valid
2 1 Binary Input Change without Time 1 81,82 Y
2 2 Binary Input Change with Time 1 81,82 Y
2 3 Binary Input Change with Relative Time 1 81,82 Y
3 0 Double Binary Input - All Variations 1 All valid
3 1 Double Binary Input - Packed format 1 81,82 Y
3 2 Double Binary Input - with flags 1 81,82 Y
4 0 Double Binary Input change - All Variations 1 All valid
4 1 Double Binary Input change - without Time 1 81,82 Y
4 2 Double Binary Input change - with Time 1 81,82 Y
4 3 Double Binary Input change - with Relative Time 1 81,82 Y
10 0 Binary Output Status - All Variations 1 All valid
10 1 Binary Output 1 81,82 Y
10 2 Binary Output - with Status 1 81,82 Y
12 0 Binary Control Command - All Variations
12 1 Control Relay Block 3,4,5,6 17,28,39 Y
12 2 Pattern Control Block 1 N
12 3 Pattern Mask 1 N
13 0 Control Command Event - All Variations 1 N
13 1 Control Command Event - Command Status 1 N
13 2 Control Command Event - T.T Command Status 1 N
20 0 Binary Counter - All Variations 1 All valid
20 1 32-Bit Binary Counter 1 81,82 Y
20 2 16-Bit Binary Counter 1 81,82 Y
20 3 32-Bit Delta Counter 1 81,82 Y
20 4 16-Bit Delta Counter 1 81,82 Y
