APPENDIX C: D20E MODULE DNP3 SERVER PROFILE
20 5 32-Bit Binary Counter without flag 1 81,82 Y
20 6 16-Bit Binary Counter without flag 1 81,82 Y
20 7 32-Bit Delta Counter without flag 1 81,82 Y
20 8 16-Bit Delta Counter without flag 1 81,82 Y
21 0 Frozen Counter - All Variations 1 All valid
21 1 32-Bit Frozen Counter 1 81,82 Y
21 2 16-Bit Frozen Counter 1 81,82 Y
21 3 32-Bit Frozen Delta Counter 1 81,82 Y
21 4 16-Bit Frozen Delta Counter 1 81,82 Y
21 5 32-Bit Frozen Counter with Time 1 81,82 Y
21 6 16-Bit Frozen Counter with Time 1 81,82 Y
21 7 32-Bit F-Delta Counter with Time 1 81,82 Y
21 8 16-Bit F-Delta Counter with Time 1 81,82 Y
21 9 32-Bit Frozen Counter without flag 1 81,82 Y
21 10 16-Bit Frozen Counter without flag 1 81,82 Y
21 11 32-Bit F-Delta Counter without flag 1 81,82 Y
21 12 16-Bit F-Delta Counter without flag 1 81,82 Y
22 0 Binary Counter Change - All Variations 1 All valid
22 1 32-Bit Binary Counter Change 1 81,82 Y
22 2 16-Bit Binary Counter Change 1 81,82 Y
22 3 32-Bit Delta Counter Change 1 81,82 Y
22 4 16-Bit Delta Counter Change 1 81,82 Y
22 5 32-Bit Binary Counter Change without flag 1 81,82 Y
22 6 16-Bit Binary Counter Change without flag 1 81,82 Y
22 7 32-Bit Delta Counter Change without flag 1 81,82 Y
22 8 16-Bit Delta Counter Change without flag 1 81,82 Y
23 0 Frozen Counter Change - All Variations 1 All valid
23 1 32-Bit Frozen Counter Change 1 81,82 Y
23 2 16-Bit Frozen Counter Change 1 81,82 Y
23 3 32-Bit Delta Frozen Counter Change 1 81,82 Y
23 4 16-Bit Delta Frozen Counter Change 1 81,82 Y
23 5 32-Bit Frozen Counter Change without flag 1 81,82 Y
23 6 16-Bit Frozen Counter Change without flag 1 81,82 Y
23 7 32-Bit Delta Frozen Counter Change without flag 1 81,82 Y
23 8 16-Bit Delta Frozen Counter Change without flag 1 81,82 Y
30 0 Analog Input - All Variations 1 All valid
30 1 32-Bit Analog Input 1 81,82 Y
30 2 16-Bit Analog Input 1 81,82 Y
30 3 32-Bit Analog Input without flag 1 81,82 Y
30 4 16-Bit Analog Input without flag 1 81,82 Y
30 5 Short Floating 1 81,82 Y
32 0 Analog Input Event - All Variations 1 All valid
32 1 32-Bit Analog Input Event without Time 1 81,82 Y
32 2 16-Bit Analog Input Event without Time 1 81,82 Y
32 3 32-Bit Analog Input Event with Time 1 81,82 Y
Object Request
(see Table 48)
Response
(see Table 49)
Number Variable Description FC (hex) Qualifier (hex) FC (hex) Used
