GE Multilin D20E User Manual

APPENDIX C: D20E MODULE DNP3 SERVER PROFILE
D20E ETHERNET I/O MODULE INSTRUCTION MANUAL GE INFORMATION 133
The request qualifiers (see Table 47) cover the:
• Basic qualifier of all ranges
• Start/stop range of 0x06, 0x00, 0x01;0x02
• Counting range 0x07,0x08 and 0x09
• List range of 0x17, 0x28 and 0x39
Table 47: Qualifier used in DNP3 subset definition
32 4 16-Bit Analog Input Event with Time 1 81,82 Y
32 5 Short Floating 1 81,82 Y
32 6 Long Floating 1 81,82 Y
32 7 Short Floating with Time 1 81,82 Y
50 0 Time and Date - All Variation 1
50 1 Time and Date 2 81 Y
50 2 Time and Date with interval 2 81
50 3 Last Recoded Time 2 81
51 0 Time and Date Common Time-of-Occurrence 1 Y
51 1 Time and Date CTO 1 81 Y
51 2 Time and Date CTO with interval 1 81 N
51 3 Last Recoded Time CTO 1 81 N
52 0 Delay Measurement - All Variation 17
52 1 Delay Measurement - Time Delay Coarse 17 81 Y
Object Request
(see Table 48)
Response
(see Table 49)
Number Variable Description FC (hex) Qualifier (hex) FC (hex) Used
Qualifier Use in Request Used in Response
0x00, 0x01,0x02 A range of static points, or a single point with a point,
where:
• 0x00 - 8-bit start and stop indices;
• 0x01 - 16-bit start and stop indices;
• 0x02 - 32-bit start and stop indices;
Static objects.
0x06 All points Not valid
0x07, 0x08,0x09 A limited quantity of events (count beginning with 0).
A single point with no number (e.g., Time and Data).
A single point with no
number (e.g. Time and
Date)
0x17, 0x28,0x39 Control and list of points (usually one or more
unrelated points).
For point:
• #1 to #255 use 0x17;
• #256 to use 0x28;
• #655356
Event objects (usually one
or more unrelated points)
