D20E ETHERNET I/O MODULE INSTRUCTION MANUAL GE INFORMATION 139
D20E Ethernet I/O Module
Appendix F: Frequently Asked
Questions
Frequ ently A sked Ques tions
This appendix answers some frequently and commonly asked D20E questions:
• How do you configure the double Digital Input points?
• How do you identify what D20E configuration is currently running?
• How do you configure a Counter?
• How do you set the Analog Input to match the legacy hardware (signed 16 bit
integer)?
• How do you operate a R/L (raise/lower) Digital Output point)?
• How do you operate control output points?
• How do you access the system status information?
• How do you access the Event Log?
• How do you test previously configured input/output points using DAPserver Studio?
• How do you setup Time Synchronization?
Questions and answers
Q: How do you configure the double Digital Input points?
A: Refer to section: Double digital input configuration procedure on page 59 for this
configuration procedure.
Q: How do you identify what D20E configuration is currently running?
A: Method 1: To view the firmware version using DAPserver Studio:
1. Go to Device menu > Explore tab.
Result: The Explore window appears.
2. Scroll down the main (top) window displayed for SYSTEM, REAL-TIME info
3. Observe the information for the FMWVER line item.
