D20E ETHERNET I/O MODULE INSTRUCTION MANUAL GE INFORMATION 37
D20E Ethernet I/O Module
Chapter 3: Configuring the D20E
Firmware
Configuring the D20E Firmware
This chapter describes the set up required to start operation of a D20E module. The D20E
module is then ready to be configured and monitored, and ready for the download of
projects files.
This chapter provides the following information:
• Set up procedure on page 37
• Working with projects on page 43
• Configuring D20E modules on page 49
• Configuring points on page 55
• Digital input points on page 55
– Counter points on page 60
• Analog input points on page 63
• Control output points on page 69
• Check operation of the D20E on page 73
• Make D20E device setting changes on page 74
Set up procedure
To set up for the configuring, monitoring and downloading of projects to the D20E module,
perform the following tasks:
1. Connect the D20E module (port 1) to a Windows PC with an Ethernet cable as shown
in Figure 6.
A standard Ethernet cable can be used if connecting to a network with an Ethernet
switch.
