CHAPTER 3: CONFIGURING THE D20E FIRMWARE
D20E ETHERNET I/O MODULE INSTRUCTION MANUAL GE INFORMATION 71
Off Name Specify the name of the digital output point
when it is in an off state:
• Single Point Digital Input - Off state = 0
• Double Point Digital Input - Off state = 1
The name can be entered manually, or double-
click and select from the drop-down menu.
ASCII
On Name Specify the name of the digital output point
when it is in an on state:
• Single Point Digital Input - On state = 1
• Double Point Digital Input - On state = 2
The name can be entered manually, or double-
click and select from the drop-down menu.
ASCII
Control settings
Reference
Name
Specify a text string that combines the bay
name, group name, and provider name from
the General tab.
Associate
Output DI or
Event
Specify the feedback digital input (typically a
pseudo digital input or counter) for the digital
output. The associated digital input point will
change state based on the digital output state.
Trip
Interlocking
Specify the interlock condition for trip
operation on the digital output using script.
Close
Interlocking
Specify the interlock condition for close
operation on the digital output using script.
Operate
Method
Specify the Digital Output method that applies
to this DO.
The following operation methods are available:
•Direct
• Select Before Operate (SBO)
If this value is set to Direct, both the Direct and
Select Before Operate commands are
accepted by this point.
If this value is set to SBO, only the Select Before
Operate command is accepted.
Operate
Timeouts
Specify the maximum amount of time, in
milliseconds, allowed between the Select
command and Operate command.
The setting is applied when the Operate
Method is set to SBO.
1000 to 60000
milliseconds
10000
(10
seconds)
Providers - Protocol settings
Reference
Name
Specify a text string that combines the bay
name, group name, and provider name from
the General tab.
Physical Index Specify the index number of a Digital Output
point. It is recommended to use one-based
increment counting.
1, 2, …, 8.
Type Specify the relay control type.
The relay type setting is to coincide with
hardware jumper setting in either
Table
22: D20E-K - summary of control types
and jumper setting positions on page 89, or
Table 27: D20E-C - summary of control
types and jumper setting positions on page
99.
Trip/Close
Form C
DPSTl
Raise/Lower
Trip/
Close
Activity Timer Specify the length of time (in milliseconds)
before the signal is set to inactive.
0 to 100000 ms 10 ms
Setting Descriptions Range Default
