88 GE INFORMATION D20E ETHERNET I/O MODULE INSTRUCTION MANUAL
CHAPTER 7: CONNECTING FIELD WIRING TO THE D20E MODULE
11 Shield/Screen Ground 61 Shield/Screen Ground
12 Analog Input 8+ 62 Analog Input 8‒
13 Analog Input 9+ 63 Analog Input 9‒
14 Shield/Screen Ground 64 Shield/Screen Ground
15 Analog Input 10+ 65 Analog Input 10‒
16 Analog Input 11+ 66 Analog Input 11‒
17 Shield/Screen Ground 67 Shield/Screen Ground
18 Analog Input 12+ 68 Analog Input 12‒
19 Analog Input 13+ 69 Analog Input 13‒
20 Shield/Screen Ground 70 Shield/Screen Ground
21 Analog Input 14+ 71 Analog Input 14‒
22 Analog Input 15+ 72 Analog Input 15‒
23 Shield/Screen Ground 73 Shield/Screen Ground
24 Analog Input 16+ 74 Analog Input 16‒
25 Analog Input 17+ 75 Analog Input 17‒
26 Shield/Screen Ground 76 Shield/Screen Ground
27 Analog Input 18+ 77 Analog Input 18‒
28 Analog Input 19+ 78 Analog Input 19‒
29 Shield/Screen Ground 79 Shield/Screen Ground
30 Analog Input 20+ 80 Analog Input 20‒
31 Analog Input 21+ 81 Analog Input 21‒
32 Shield/Screen Ground 82 Shield/Screen Ground
33 Analog Input 22+ 83 Analog Input 22‒
34 Analog Input 23+ 84 Analog Input 23‒
35 Shield/Screen Ground 85 Shield/Screen Ground
36 Analog Input 24+ 86 Analog Input 24‒
37 Analog Input 25+ 87 Analog Input 25‒
38 Shield/Screen Ground 88 Shield/Screen Ground
39 Analog Input 26+ 89 Analog Input 26‒
40 Analog Input 27+ 90 Analog Input 27‒
41 Shield/Screen Ground 91 Shield/Screen Ground
42 Analog Input 28+ 92 Analog Input 28‒
43 Analog Input 29+ 93 Analog Input 29‒
44 Shield/Screen Ground 94 Shield/Screen Ground
45 Analog Input 30+ 95 Analog Input 30‒
46 Analog Input 31+ 96 Analog Input 31‒
47 Shield/Screen Ground 97 Shield/Screen Ground
48 Analog Input 32+ 98 Analog Input 32‒
49 External AI DC Loop Supply (+) 99 External AI DC Loop Supply (‒)
50 Chassis Earth Ground (PE GND on #10
stud)
100 Chassis Earth Ground (PE GND on #10
stud)
TB2 Descriptions TB2 Descriptions
