GE RAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

3-8 Section 3-3 - Receiving and Unpacking the Equipment

Remove the top cover and top plate.

Remove the three Plastic Joints from the outer sleeve..

Remove the outer sleeve and the monitor pad.

Table 3-5 Unpacking Procedure

Step Task
