page | 177
Appendix
Conguration Worksheets
Matrix:
Name Manufacturer Model Control Gateway Port / IP Address Amp Input Connects to: on Input: Location Notes:
Output 1 Output 2 Output 3 Output 4 Output 5 Output 6 Output 7 Output 8
Name Manufacturer Model Control Gateway Port / IP Address
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8
Remove page and photocopy if necessary
