Gefen EXT-GAVA - Adding a Receiver

page | 53
Adding Rooms
Using the GAVA Wizard
Adding a Receiver
1. Type a descriptive name for the receiver in the A/V Receiver eld. For this example,
we’ll just use “A/V Receiver”.
2. Select the manufacturer from the Manufacturer drop-down list. We will select
“Denon”.
The drivers for the each model will have certain control capabilities. We have selected
a Denon amplier. The model we are using is the AVR2113. This particular model
has two methods of control: IP control or RS-232 control. We will illustrate the
conguration for both methods, beginning on the next page.
Manufacturer
Select the device Manufacturer from
this drop-down list.
Next
Click the Next button after
the Name, Manufacturer, and
Model have been entered.
Name
Type a descriptive name for
the receiver in the Name
eld.
