Adding Control Gateways
Using the GAVA Wizard
Adding a Lutron Lighting Control System
Lutron RadioRA® 2 and HomeWorks® QS systems should rst be set up, congured,
programmed, and downloaded to the Lutron controller via the Lutron software before
adding them to the GAVA system. See the Lutron documentation for details. If you have
a KNX system, the following procedure will be similar. See Using the GAVA with a KNX
Automation System for details on preparing the KNX system for use with the GAVA. After
completing the design, programming, activation, and transfer procedure, connect to the
Main Repeater via IP.
Extracting the XML from the Lutron software
1. Using Internet Explorer Web browser, go to http://<MainRepeaterIPAddress>/DbX-
mlInfo.xml (where <MainRepeaterIPAddress> is the IP address assigned to the
Lutron Main Repeater.
• When using a static IP address, the IP address is assigned in the RadioRA 2
software.
• When using a dynamically-assigned IP address (DHCP), the IP address can be
obtained from your router’s DHCP table or by using the Fing utility (see Using the
“Fing” App). Refer to the router documentation for details.
• Example: http://192.168.2.105/DbXmlInfo.xml
2. Click on the File menu at the top of the page in the Web browser.
3. Select Save As...
4. Save the XML le to the desired location on your computer.
Refer to the next page for the listing of a sample XML le.
IMPORTANT: If you have several Lutron systems, then you should
change the name before saving to prevent overwriting another
conguration le.
