that the waste tray is empty. Press the ▲ (up) or ▼ (down) keys to highlight the other
switch/sensor inputs and view their status.
Mug Sensor - Current: This menu gives the engineer an indication as to the
efficiency of the SureVend™ sensor. The range for correct operation is a numerical
value between 51 - 255.
1. Highlight Mug Sensor - Current from the
Switches & Sensors menu and press the ↵ (Edit)
key. The LCD will display the screen as shown
opposite. The numerical value shown indicates
the current mug sensor value.
2. The Mug Sensor value can be any number between 0 and 255 and represents the
current value read from the sensor. The engineer can test the mug sensor by
blocking the SureVend™ sensors located in the drink dispense area. The value
displayed in the status line will drop as the sensors are blocked.
Mug Sensor - Average: This menu gives the engineer an indication as to overall
efficiency of the SureVend™ sensor.
1. Highlight Mug Sensor - Average from the
Switches & Sensors menu and press the ↵ (Edit)
key. The LCD will display the screen as shown.
The value displayed represents the average
sensor calibration value.
5. Test Vend Without Cups: This menu allows the engineer to test vend a selection
without dropping a cup.
Note: Ensure that a suitable container is placed under the dispense position to receive
the vend.
1. Highlight Test Vend Without Cups in the main
Test menu and press the ↵ (Edit) key. The LCD
will display the screen as shown opposite. Make
a selection using the drink selection keypad and
press the START button. The machine will
dispense the selection without dropping a cup.
2. Press the X (Exit) key to return to the main test menu screen.
