Section 1 - Machine Specifications
1.1 Specifications
* Height includes visible bean container.
All weights and dimensions are approximate and are for guidance only.
1.2 Canister Capacities
1.3 Water Filter
Genesis machines fitted with the CoEx® espresso brewer must be connected to the
water supply via a scale inhibiting water filter.
3
Technical Manual
Espresso (B2C)
Height 33.85 in. (860 mm)*
Depth 23.23 in. (590 mm)
Width 21.26 in. (540 mm)
Weight 154 lbs. (70 kg)
Cup Capacity 230
Number of Canisters 6
Electrical Requirements
(i) Voltage 115 V ac
(ii) Current 12 Amp, single phase
(iii) Frequency 60Hz
Water Services
Pressure 10 psi (69 KPa) - 80 psi (522 KPa)
Canister Capacities (Approximate)
Espresso Coffee Beans 4.0 lbs. - 240 cups
Freshbrew Coffee 1.2 lbs. - 130 cups
Chocolate 5.0 lbs. - 130 cups
French Vanilla 5.0 lbs. - 130 cups
Topping 3.0 lbs. - 180 cups
Sugar 6.0 lbs. - 1075 cups
