Section 2 - Installation Procedure
2.1 Location Preparation
After the machine is unpacked and placed near its permanent location, you need to
make sure that you have the correct electrical and water service.
The machine needs electrical power as shown in the following table.
NOTE: Each machine should have its own electrical circuit.
Power Requirements
This machine is supplied with a service cord for the country of use and is terminated
in a grounding type plug. The wall receptical used for this machine must be properly
polarized, grounded and of the correct voltage. Operating the machine from a source
of low voltage will VOID YOUR WARRANTY. Each machine should have its own
electrical circuit and that circuit should be protected with a circuit breaker or fuse
conforming to local regulations.
Voltage Check - Place the levels of a voltmeter across the LINE (LIVE) and
NEUTRAL terminals of the wall receptical. The voltmeter should indicate 110-130 volts
ac for 120 volt, 60 Hz locations.
Polarity Check - Place leads of a voltmeter across the LINE (LIVE) and GROUND
terminals ff the wall receptical. The voltmeter should indicate 110-130 volts ac for 120
volt, 60 Hz locations.
Noise Potential Check - Place leads of a voltmeter across the NEUTRAL and
GROUND terminals ff the wall receptical. The voltmeter should indicate 0 volts ac. A
measurement greater than 1.5 - 2.0 volts ac could result in problems for the machines
electronic circuitry caused by electrical noise.
Any deviation from these requirements could result in unreliable performance from
the machine.
7
Technical Manual
Country Volts Frequency (Hz) Current (Amps)
Canada 115 60 15
United States 115 60 15
To Next Page
