As the engineer presses the final zero, the AM
value will appear within a dotted box and the
text at the bottom of the LCD will now read
‘Press Arrows To Select’. Press the
▲ (up) or
▼ (down) key until PM appears in the box.
Pressing the ↵ (Edit) key will move back to the Clock menu screen and save the
new time to the machines memory. Confirm that the status line at the bottom of
the screen displays the correct time when Time is highlighted.
Note: When set to 12 hour format, the program will only allow the engineer to
set the numbers 0 or 1 in the first field. Once the number 24 has been entered
via the
▲ (up) or ▼ (down) keys to indicate 24 hour format, the engineer can
reset the first two values to reflect 10:30 PM in 24 hour format e.g. 22:30.
3. Daylight Saving: From the Clock menu screen
press the
▼ (down) key to highlight the Daylight
Saving menu followed by the ↵ (Edit) key. The
LCD will display the screen as shown opposite.
By default daylight savings time is set to Off. To
choose one of the available options, press the
▲ (up) or ▼ (down) key until
selected (indicated by the filled radio button) followed by the ↵ (Edit) key. Ensure
that the required setting is displayed in the status line at the bottom of the screen.
Press the X (Exit) key to return to the main menu.
3. Language Setup: From this menu the engineer can specify the language that the
machine will use to display messages, programming information etc. The default
language for the machine is set to English U.S. To change the language setting:
1. From the System Settings menu, use the
▼
(down) key to highlight the Language Setup menu
and press the ↵ (Edit) key. The LCD will display
the screen as shown opposite. Using the
▲ (up)
or
▼ (down) keys, select the desired language
option (indicated by the filled radio button).
2. Press the ↵ (Edit) key to save the language option and return to the System
Settings menu. Verify that the chosen language is displayed in the status line at the
bottom of the display when Language Setup is highlighted.
4. Monetary: From this menu the engineer can select the type of coin/card mechanism
or note reader fitted to the machine, select the coin set and configure values for low
change, multiple vends, credit for failed vends etc.
38
Technical Manual
