The keys are configured as follows:
Note: To change from lower to upper case, press the START key.
3. When complete, press the X (Exit) key to return to the Machine Information
menu screen. Press the ▼ (down) then ↵ (Edit) keys to highlight then enter the
Machine Location screen. Enter a unique machine location using the 0-9 drink
selection keys as described above. When complete press the X (Exit) key.
2. Clock: The machine displays the current time in either 12 or 24 hour format.
Upon entry to the System Settings menu, the Clock sub menu is highlighted. Press the
↵ (Edit) key to access the Clock sub menu screen. This menu allows the engineer to
set the date, time and daylight saving via 3 separate sub menus.
Note: The current date, time and daylight saving (when highlighted) held in the
machines memory are displayed in the status line at the bottom of the screen.
1. Date: Press the ↵ (Edit) key to enter the Date menu. The date is displayed in
day, month, year format. To set the date, e.g. 27th January 2006, press the
sequence 2-7-0-1-0-6 using the appropriate number keys on the drink selection
keypad.
Note: The text ‘Press 0-9 to Edit Value’
displayed in the status line at the bottom of the
screen will alternate with the text ‘Press */? To
Change Mode’. Pressing the START key on the
drink selection keypad allows the date to be
displayed in month, day, year format.
Pressing the ↵ (Edit) key will move back to the Clock menu screen and save the
date to the machines memory. Confirm that the status line at the bottom of the
screen displays the correct date when Date is highlighted.
2. Time: From the Clock menu screen press the
▼ (down) key to highlight the Time
menu followed by the ↵ (Edit) key. The LCD will
display the screen as shown opposite.
By default the time is displayed in 12 hour
format. To enter a time of 10:30 PM press the
sequence 1-0-3-0 on the drink selection keypad.
