10.6 Output Circuit
78
Technical Manual
ESPRESSO
VALVE
DISPENSE HEAD
MOTOR
BREWER
MOTOR
PRESSURE
VALVE
VALVE 2
(HOT WATER)
J10
J14
J16
SSR GND
SSR 24V
SOLID STATE
RELAY
RED/ORANGE
RED/ORANGE
ORANGE/BLACK
ORANGE/PINK
WHITE
PURPLE/BLACK
