11.2 Adjusting The Cup Drop Mechanism
When changing the type or size of cup vended from the machine, it may also be
necessary to adjust the cup drop mechanism to accommodate the new cups. Proceed
as follows:
1. Open the door and swing the cup turret assembly out of the machine. Carefully
lift and remove the four transparent cup sleeves from the cup drop unit. Discard
any cups that may be left over.
2. Place a minimum of 4 new cups into the cup ring. Observe the clearance as shown
in the illustration below.
86
Technical Manual
Error Diagnostics Fault
Message Screen Text Description
Temporarily Single card reader Transient error with card reader, but card
Out Of Service error reader in service. Unable to communicate
with the card reader
Temporarily Card reader reports Repeatable error with card reader, but
Out Of Service a comm error card reader in service. Unable to
communicate with card reader
Temporarily Card reader error Problem with card reader.
Out Of Service Manufacturing error detected
Temporarily Card reader failed Card reader is out of service
Out Of Service OOS err
Temporarily Card reader reports Comm error with card reader.
Out Of Service comm error & is OOS Out of service
Temporarily Card jammed in Card jam
Out Of Service card reader
Temporarily Card reader failure Problem with card reader.
Out Of Service Manufacturing error detected
Temporarily Card reader Card reader needs servicing
Out Of Service requests servicing
An Error Has - Low water during a CoEx®
occurred brewer clean
Sorry Out Of Service No Water No Water Available
No Water Available Available
