IMPORTANT: Pressing switch 10 also informs the machine software that the
B2C system has been drained ensuring that the B2C system will automatically fill
before heating on power up. This is very important and must not be overlooked.
2. Once the B2C system has been cooled the LCD will display the message ‘Machine
cooled’ and water will stop pumping through the system. Remove the waste tray
and empty the contents before re-fitting to the machine.
3. Remove the safety key from the door switch to turn off the power to the machine.
4. Close the fresh beans outlet slide and remove the fresh beans container. Rotate
ingredient canister outlets to upright position and remove the canisters. DO NOT
place them on the floor.
5. Loosen the 4 screws securing the top cover and
remove. Remove the brewer waste bucket from the
machine. Loosen the 4 screws securing the lower
cover.
6. Remove the lower cover from the machine to expose
the boiler blanking plug (1). Hold the collar and
remove the plug. Attach a length of silicone tube to
the outlet to act as a drain. Place the trailing end into
an empty bucket.
7. Remove the air intake blanking plug (2) located in the
top LH corner of the machine. All water will be
ejected from the system via the boiler drain into the
bucket allowing the engineer to safely work on system
components.
To refill the system, proceed as follows:
1. Remove the drain tube from the boiler drain and replace the blanking plug. Refit
the air intake blanking plug. Refit both the top and lower covers to the machine.
Ensure all fixing screws are re-tightened.
2. Refit the fresh coffee beans container into the machine and open the outlet slide.
Refit ingredient canisters into the machine, rotating outlets to their correct
operating position. Refit the brewer waste bucket into the machine.
88
Technical Manual
