10.3 Control Board Connections - 1
The diagram below illustrates the connections between the control board and the
console board, SureVend™ sensor, pressure tank and thermistor.
75
Technical Manual
LED 2 POWER
J6J10
CONSOLE CONSOLE
IrDA
MAIN
CONTROLLER
BOARD
J5
PRESSURE
TANK
LED 1 COMMUNICATIONS
THERMISTOR
WHITE
BLACK
BLUE
RED
BLACK
BLUE
RED
BLACK
RED
BLACK
BLACK
WHITE
SUREVEND
SENSOR
MAIN
CONTROLLER
BOARD LINK
RIBBON CABLE
6
8
J4
7
9
3
2
1
4
5
IR OUT-TX
IR IN-TX
THERM COM
THERM OUT
5V+
} SURE VEND SENSOR
} THERMISTOR
PLUG
J9A J9B
