The Monetary menu can display up to 11 sub menus, depending on machine
configuration, as listed below:
• Coin Mechanism
• Bill Validator
• Card Reader
• Bill Stack Option
• Multiple Vend Mode (Only if MDB mech. selected)
• Change Without Purchase (Only if MDB mech. selected)
• Low Change Message (Only if MDB mech. selected)
• Accept On Low Change (Only if MDB mech. selected)
• Credit for Failed Vend (Only if MDB mech. selected)
• Card Re-Value (Only if MDB card reader / key system is selected)
• Display Coin Set
1. Select The Coin Mechanism
1. From the Monetary menu highlight Coin
Mechanism and press the ↵ (Edit) key. The Coin
Mechanism screen allows the engineer to select
one of the options shown. Using the
▲ (up) or
▼ (down) keys, select the desired coin
mechanism option (indicated by the filled radio
button).
2. Press the ↵ (Edit) key to save the selection and return to the Monetary menu.
Verify that the chosen coin mechanism option is displayed in the status line at the
bottom of the display.
Note: An Executive Card/Key system (when fitted) is enabled when Exec Coin
Mechanism is selected.
2. Select The Bill Validator (MDB Systems Only)
An MDB bill validator is supported and can be mounted in the optional base cabinet
option.
3. Select The Card/Key Reader (MDB Systems Only)
Note: An Executive protocol card/key system emulates an Executive coin mechanism
and is selected via the Coin Mechanism menu.
39
Technical Manual
